Santa Cruz Hightower CC Frame

Santa Cruz Hightower CC Frame
  • Color: Matte Melon
  • Color: Gloss Carbon
$2,900.00 - $3,699.00
$2,900.00 - $4,099.00
Color:
Size: Select size
Please select options Unavailable

Details

Our greatest hits compiled into one bike. Just hit play.

If ever a bike resembled your most cherished mix tape compilation, the Hightower is it. Featuring our lower-link mounted shock design, updated, adjustable geometry, this "Engineering Best Of..." assembles some of our biggest design pleasers into one belter of a road-trip companion.

The Hightower has been a does-it-all-well trail bike since its inception. More maneuverable than its longer-travel sibling, the Megatower, and more at home in the steep-and-chunky than its snappy cousin Tallboy, Hightower excels when the route covers 'all points in between,' and descents come courtesy of some big-ass climbs. The VPP suspension's lower-link-mounted shock creates a nearly linear leverage curve, meaning it mops up bumps of all sizes and maintains the kind of progressivity normally reserved for our V10 DH bike!

145mm of rear travel complemented by a 150mm front end gives Hightower just a bit more front and rear travel over the first generation model. Combined with a slacker 65-degree head tube angle, the Hightower still sits squarely in the Goldilocks zone, but with a touch more "Oh sh*t, get me out of here" capability when the porridge gets too hot!

Balancing stiffness and weight savings in all the right places is a hallmark of all Santa Cruz carbon frames, and the Hightower flies the flag yet higher. The advanced composite chassis tracks well across all trail surfaces, holds a line, and is reactive to rider directions while isolating pedal-influenced inputs.

The Hightower also has a bonus disc to heighten the experience: the flip chip. In the High setting, the BB height is a little higher for those tricky tech trails and/or when Plus sized tires are required. In the Low position, the shock rate is more progressive to provide additional bottom-out resistance. Whatever mood you're in, the tone of the Hightower can be adapted to meet your individual taste.

And, speaking of taste, there's room for a water bottle inside the main frame and a threaded BB for convenience. There's refined cable routing for better shifting performance, simpler installation, and no cable rub. On top of that, there's a tailgate shuttle guard, downtube protector, shock fender, and noise-canceling chainstay protector to keep things quiet.

The lifetime frame warranty and lifetime pivot bearing replacement policy assure you that the Hightower will keep delivering the hits for years to come.

High Setting
bike frame with labeled dimensions
Bike Sizes:
SMLXLXXL
A. Reach 428mm 453mm 473mm 493mm 518mm
B. Stack 601mm 610mm 619mm 637mm 660mm
C. Standover 704mm 718mm 717mm 718mm 709mm
D. Effective Top Tube 566mm 594mm 618mm 645mm 679mm
E. Head Tube Angle 65.5° 65.5° 65.5° 65.5° 65.5°
F. Head Tube Length 90mm 100mm 110mm 130mm 155mm
G. Seat Tube Angle 77.1° 77.0° 76.8° 76.6° 76.3°
H. Seat Tube Length 380mm 405mm 430mm 460mm 500mm
I. Bottom Bracket Height 344mm 344mm 344mm 344mm 344mm
J. Bottom Bracket Drop 29mm 29mm 29mm 29mm 29mm
M. Wheelbase 1178mm 1207mm 1231mm 1260mm 1301mm
N. Front to Center 745mm 774mm 798mm 827mm 862mm
O. Chainstay Length 433mm 433mm 433mm 433mm 439mm
Low Setting
bike frame with labeled dimensions
Bike Sizes:
SMLXLXXL
A. Reach 425mm 450mm 470mm 490mm 515mm
B. Stack 603mm 612mm 621mm 639mm 662mm
C. Standover 699mm 713mm 713mm 713mm 704mm
D. Effective Top Tube 567mm 596mm 619mm 646mm 680mm
E. Head Tube Angle 65.2° 65.2° 65.2° 65.2° 65.2°
F. Head Tube Length 90mm 100mm 110mm 130mm 155mm
G. Seat Tube Angle 76.7° 76.6° 76.5° 76.3° 76.0°
H. Seat Tube Length 380mm 405mm 430mm 460mm 500mm
I. Bottom Bracket Height 340mm 340mm 340mm 340mm 340mm
J. Bottom Bracket Drop 33mm 33mm 33mm 33mm 33mm
M. Wheelbase 1179mm 1208mm 1232mm 1261mm 1296mm
N. Front to Center 745mm 774mm 798mm 827mm 862mm
O. Chainstay Length 434mm 434mm 434mm 434mm 440mm

Specs

Frame Hightower AL
Fork 150-170mm
Rear Shock RockShox Super Deluxe Ultimate
Wheels 29-inch
Axles 12x148mm
Tires 2.4-inch
Bottom Bracket 73mm threaded
Chainrings 36t max
Front Derailleur No compatibility
Headset Integrated (IS41/52)
Seatpost 31.6mm

* Subject to change without notice.

Part Numbers

Option UPC MPN Store SKU
Gloss Carbon / Small 192219221304 68-22202-2-745-2099
Gloss Carbon / Medium 192219221267 68-22202-3-745-2099 210000050463
Gloss Carbon / Large 192219221229 68-22202-4-745-2099 210000055447
Gloss Carbon / X-Large 192219221182 68-22202-5-745-2099
Gloss Carbon / XX-Large 192219221144 68-22202-6-745-2099
Matte Melon / Small 192219221328 68-22202-2-744-2099
Matte Melon / Medium 192219221281 68-22202-3-744-2099
Matte Melon / Large 192219221243 68-22202-4-744-2099
Matte Melon / X-Large 192219221205 68-22202-5-744-2099 210000051320
Matte Melon / XX-Large 192219221168 68-22202-6-744-2099
