BMC Teammachine R 01 MOD

BMC Teammachine R 01 MOD
$5,999.00
Color: Carbon Black/Cool White
Size: Select size
Please select options Unavailable

Details

The all-new BMC Teammachine R was designed for a special breed of cyclist. Light enough to ascend the most demanding climbs and stiff enough to endure the most watt-crushing sprints, the Teammachine R is the ultimate race bike. The Teammachine R 01 MOD comes with BMC's ICS Carbon Aero Cockpit and integrated Aerocore bottle cages.

The ultrawide fork legs are unlike anything else seen in the peloton and help keep turbulent air, created by the front wheel, away from the frame.

The ICS Carbon Aero Cockpit, with its progressive and aerodynamic shape, is the perfect match for this bike. Featuring a narrow top width, allowing an efficient aero position with a greater width at the drops providing incredible control at high speed.

We call it the "Mariana Bottom Bracket" because it's the deepest bottom bracket we have ever made on a road bike and this perfectly optimizes the surface area for cleaner airflow.

The new seatpost is slimmer, deeper, more compliant, and lighter than ever. With the new seatpost clamp mechanism now easier to access and maintain, including an integrated number plate holder making it the smartest way to get race-ready.

Sizes:
Size475154565861
Rider Height <166 166 - 174 172 - 180 178-186 184-192 >190
Reach 368 378 387 393 402 409
Stack 504 528 548 563 582 608
Bar Reach 72.5 72.5 72.5 72.5 72.5 72.5
Bar Width 360/420 360/420 360/420 360/420 360/420 360/420
BB Drop 69 69 69 69 69 69
Crank Length 170 170 172.5 172.5 175 175
Fork Length 367 367 367 367 367 367
Fork Rake 48 48 43 43 43 43
Front Center 568 586 589 599 614 630
Head Tube 108 133 149
Head Tube Angle 71.5 71.5 72.3 72.3 72.3 72.3
Rear Center 410 410 410 72.3 410 410
Seat Angle 74 74 73.5
Seat Tube 418 463 499 519 541 570
Seatpost Length 335 335 385 385 405 405
Seatpost Offset 10 10 10 10 10 10
Stem Angle -15 -15 -15 -15 -15 -15
Stem Length 90 100 100 110 110 120
Top Tube 522 532 552
Trail 63 63 63 63 63 63
Wheelbase 968 986 989 999 1015 1030

Specs

Frame Teammachine R 01 Premium Carbon with Aerocore Design | ICS Technology, Stealth Cable Routing | Integrated Aerocore Bottle Cages | Stealth Dropout Design | PF86 Bottom Bracket | Flat Mount Disc | 12x142mm Thru-Axle
Fork Teammachine R 01 Premium Carbon | ICS Technology | Stealth Cable Routing | Stealth Dropout Design | Flat Mount Disc | 12x100mm Thru-Axle
Handlebars ICS Carbon Aero | One-Piece Full Carbon Cockpit
Seatpost Teammachine R 01 Premium Carbon Seatpost | 10mm Offset
Accessories & Extras Aerocore Bottle Cages

* Subject to change without notice.

Part Numbers

Option UPC MPN Store SKU
Carbon Black/Cool White / 47 07630906505113 30005521
Carbon Black/Cool White / 51 07630906505106 30005522 210000062149
Carbon Black/Cool White / 54 07630906505090 30005523
Carbon Black/Cool White / 56 07630906505083 30005524 210000062191
Carbon Black/Cool White / 58 07630906505076 30005525
Carbon Black/Cool White / 61 07630906505069 30005526 210000062193
